TRIQBRIQ WS15 | Internal wall

Internal wall system made of solid timber

TRIQBRIQ WS15 standard BRIQ 15-50 with tenons, angled view
TRIQBRIQ WS15

How does the WS15 work?

The TRIQBRIQ WS15 consists of standardised solid timber building blocks, the BRIQs. They are laid in a bond and interlocked with beech wood dowels – entirely without glue. The result is a 15 cm thick solid timber internal wall that can be combined with a variety of surfaces such as plaster, tiles or plasterboard.

TRIQBRIQ WS15 standard BRIQ 15-50, angled view
Solid instead of stud framing

The WS15 enables internal walls made of solid, glue-free timber instead of a conventional frame construction. The solid timber wall offers high material density, making it a good basis for internal wall build-ups optimised for sound insulation. In addition, thanks to its hygroscopic properties, the timber can help regulate indoor humidity.

Solid instead of stud framing

The WS15 enables internal walls made of solid, glue-free timber instead of a conventional frame construction. The solid timber wall offers high material density, making it a good basis for internal wall build-ups optimised for sound insulation. In addition, thanks to its hygroscopic properties, the timber can help regulate indoor humidity.

TRIQBRIQ WS15 standard BRIQ 15-50, angled view
Glue-free dowel system

Our connection system is based on beech wood dowels that securely and precisely interlock the individual BRIQs. This creates a stable, form-fitting structure entirely without glue. At the same time, the system remains detachable: BRIQ walls can be dismantled by material type and the BRIQs reused.

TRIQBRIQ WS15 BRIQ 15-50 without tenons, with dowel holes, angled view
Glue-free dowel system

Our connection system is based on beech wood dowels that securely and precisely interlock the individual BRIQs. This creates a stable, form-fitting structure entirely without glue. At the same time, the system remains detachable: BRIQ walls can be dismantled by material type and the BRIQs reused.

TRIQBRIQ WS15 BRIQ 15-50 without tenons, with dowel holes, angled view
Connection detail of WS15 internal wall to WS25 external wall, 3D view
Matching the external wall system

At 25 cm high, the WS15 BRIQs follow the same grid as the WS25 external wall system: the courses run through, and internal walls can be connected directly to the external wall – the matching connection detail is available. At 9 kg per standard BRIQ, no special equipment is required.

Matching the external wall system

At 25 cm high, the WS15 BRIQs follow the same grid as the WS25 external wall system: the courses run through, and internal walls can be connected directly to the external wall – the matching connection detail is available. At 9 kg per standard BRIQ, no special equipment is required.

Connection detail of WS15 internal wall to WS25 external wall, 3D view
TRIQBRIQ WS15

Product portfolio

TRIQBRIQ WS15 standard BRIQ 15-50 with dimensions: 50 cm long, 15 cm deep, 25 cm high
Standard BRIQ

The BRIQ 15-50

The standard BRIQ is the main element of the WS15. Laid in a bond and connected with beech wood dowels, it forms the 15 cm thick solid timber internal wall.

9 kg

Unit weight

50 × 15 × 25 cm

Dimensions L × D × H

8 units

Required per m² of wall

25 cm

Course height as WS25

System components

All components at a glance

With tenons for the wall surface, without tenons for the top course below the ceiling:
Two lengths in two variants make up the complete internal wall.

TRIQBRIQ WS15 standard BRIQ 15-50 with tenons, front view

BRIQ 15-50

50 × 15 × 25 cm · 9 kg

The main element of the WS15: laid in a bond, it forms the wall surface.

Standard BRIQ

TRIQBRIQ WS15 BRIQ 15-25 with tenons, front view

BRIQ 15-25

25 × 15 × 25 cm · 4.5 kg

The half BRIQ: for wall ends, door openings and length adjustment within the grid.

TRIQBRIQ WS15 BRIQ 15-50 without tenons, front view

BRIQ 15-50 oZ

50 × 15 × 25 cm · without tenons

For the top course: without tenons, it creates a level top edge on which the ceiling rests.

TRIQBRIQ WS15 BRIQ 15-25 without tenons, front view

BRIQ 15-25 oZ

25 × 15 × 25 cm · without tenons

The half BRIQ for the top course: for length adjustment directly below the ceiling.

Technical information

Everything for your planning with the WS15

Connection details

From floor and ceiling connections and the connection to external walls to wall build-ups with plaster, tiles or facing shell and door openings: the construction details for the WS15 are available as PDF, DWG and IFC.

Connection detail of WS15 internal wall to WS25 external wall, 3D view

Download portal

Application guide, BIM models and further technical documents for the WS15 in one place. After a quick registration, you get direct access to all relevant planning and execution data.

TRIQBRIQ timber construction system

Multi-award-winning

Built with the WS15

Reference project

TRIQBRIQ WS15 internal wall in the B2Square office in Pulheim
B2Square office · Pulheim

Interior fit-out Pulheim

In the B2Square office in Pulheim, a WS15 internal wall separates the workstations from the meeting area. The wall was built entirely without glue and can be dismantled, relocated or extended as required.

Interior fit-out · 86 BRIQs · Pulheim

TRIQBRIQ solid timber construction

Other wall systems

Consulting

Are you planning a project with the WS15?

Our experts will help you choose the right wall system and answer your questions about planning and implementation.
